Floorball Rink Fence Panel For Children
Floorball Rink Fence Panel For Children
Product Details
Product Description
Our floorball fence board means the front impact shield ( a rink panel ), a floor panel, a top handrail. Used manufacturing technology ensures the product is sufficiently sturdy, resilient, resistant, long-lasting and, if the need be, with easily repairable and replaceable structural parts of the product.
The 40 by 20 meters size rink needs the following number of individual segments: 52 pcs of the 2 meters, 4 pcs of the 1 meter and 4 pcs of the rounded corners. A rounded corner is expected to be 1.5 meter long on each rink side out of an imaginar corner point at an angle of 90 degree.
Product Parameters
|
Project Name |
Unit |
Test method |
Test Result |
|
Density |
g/cm² |
GB1033-86 |
0.94-0.98 |
|
Yield strength |
N/mm² |
ASTM D-638 |
15-22 |
|
Water absorption |
％ |
ASTM D-570 |
＜0.01％ |
|
Impact strength |
KJ/m² |
ISO179 |
90-170 |
|
Operating temperature |
℃ |
- |
-80 to ＋80 |
|
Shore hardness |
ShoreD |
ISO868 |
＞60 |
|
Friction coefficient |
unitless |
ASTM D-1894 |
＜0.2 |
The weight of segments:
2 meter long board : 8.8 kgs
1 meter long board : 4.4 kgs
The round corner : 9.5 kgs
Weight of the set : approximetely 515 kgs
