5% 10% 15% Boronated UHMWPE Sheet
UHMWPE
boron sheet
boronated sheet
radiation shielding
nuclear material
radiation material
radiation material
Product Details
Product Description
3%-40% Boronated Ultra High Molecular Weight Polyethylene ( UHMWPE ) radiation shielding sheets are specially designed for nuclear shielding applications. They are composed of 3%-40% Boron by weight, while the rest of the sheet is made of PE.
The Boron in these sheets shields against neutrons in a wide array of applications, including X-rays, nuclear submarines, cancer treatment facilities, nuclear power plants, seaports, airports, border protection, labs and other applications requiring attenuation of thermal neutrons.
At a lower cost and lighter weight than lead, UHMWPE radiation shielding sheets can be used to replace lead in nuclear shielding applications.
Technical specifications（based on 10％ by weight borated pe sheet with thickness 15cm）
|
Density |
≥1.028 g/cm3 |
|
Density contrast |
≤0.01 g/cm3 |
|
Coefficient of linear expansion |
8.933×10-51/℃ |
|
Heat resistance temperature |
126℃（DTA measure） |
|
Compressive strength |
≈24MPa |
|
Notch impact strength |
≈19KJ/m2 |
|
Heat deflection temperature（load P＝0.46Mpa） |
72℃ |
FEATURES
1. Lighter weight and lower cost than lead
2. High effect of machine processing
3. Corrosion resistance
4. Odorless, non-toxic
5. High impact strength
THE SIZE OF SHEET WE MANUFACTURE
Size is fixed, but thickness can be customized from 6mm to 200mm. Contact me if you want thicker one.
|
|
Length（mm） |
Width（mm） |
Thickness（mm） |
|
Size1 |
3000 |
1500 |
6-200 |
|
Size2 |
3050 |
1220 |
6-200 |
|
Size3 |
4700 |
1200 |
6-200 |
|
Size4 |
5000 |
1300 |
6-200 |
|
Size5 |
4500 |
2000 |
6-200 |
|
Size6 |
2000 |
1000 |
6-200 |
|
Size7 |
6000 |
1800 |
6-200 |
|
Size8 |
3000 |
3000 |
6-200 |
CUSTOMIZATION SERVICE
|
Boron content |
From 3％ to 40％ by weight |
|
Thickness |
6-200mm （can customized） |
|
Color |
Black/white |
|
Machine processing |
Available |
|
Logo |
Laser printing engraving or labeling |
|
Add other elements |
Available |
