Abosn product Corrosion Resistant UHMWPE Dock Bumpers Boards

Abosn product Corrosion Resistant UHMWPE Dock Bumpers Boards

Classification:

Fender Prodcut

Keywords:

fender

fender pad

dock bumper

The fender is mainly to bear the ship's landing, or other forms of impact. The fender veneer panel is mainly composed of UHMWPE material, which has the functions of light weight, impact resistance, corrosion resistance, UV resistance and aging resistance. Produced by Absen.

CONTACNT US

Product Details

UHMWPE dock marine fender pads are produced by a sintering process either from virgin or from reclaimed material (aprox. 70% reclaimed +30% virgin material - also named double-sintered or blended UHMW Polyethylene).

Specifications

Item	Test method	Unit	UHMWPE 1000-V	UHMWPE 1000-DS
Density	ISO1183-1	g/cm³	0.93-0.95	0.95-0.96
Yield Strength	ASTM D-638	N/mm²	15-22	15-22
Breaking Elongation	ISO527	％	＞200％	＞100％
Impact Strength	ISO179	Kj/m²	130-170	90-130
Abrasion	ISO15527	Steel=100	80-110	110-130
Shore hardness	ISO868	Shore D	63-70	63-75
Friction coefficient static state	ASTM D-1894	Unitless	＜0.2	＜0.2
OperatingTemperature	-	℃	-80 to ＋80	-80 to ＋80

UHMWPE Fender pads
The fender is mainly to bear the ship's landing, or other forms of impact. The fender veneer panel is mainly composed of UHMWPE material, which has the functions of light weight, impact resistance, corrosion resistance, UV resistance and aging resistance. Produced by Absen
The fenders are of reliable quality and can be used for several years or more.
Impact-resistant and wear-resistant fenders are now used in large ports or docks because of their own wear resistance or impact resistance.

The advantages of the fender itself
Firm installation, easy replacement, large contact area, small surface pressure
Ultra-high molecular weight polyethylene (UHMWPE) fenders still have the characteristics of good tensile properties, high tensile strength, and good immersion
In sea water all year round. Among them, the ultra-high molecular weight polyethylene (UHMWPE) dock fender can avoid the impact damage between the ship and the dock.

Application
Ultra-high molecular weight polyethylene (UHMWPE) dock fenders are widely used in domestic and foreign ports and wharfs because of their high impact resistance instead of traditional steel fenders
Ships in port construction
friction strip
low friction bushing
Truck Dock Piling
Fenders for Dock Plate Protection
Boardwalks and slides dredge

111

Features
High abrasion and impact resistance
anti-UV
Easy to use in processing engineering
Almost completely ineffective against chemical attacks
zero friction coefficient
Does not stick and stick
good electrical properties
Very good performance in low temperature applications
Maximum temperature: 180°F
Water absorption < 0.01%

Size, color and shape are processed according to customer's production requirements
We have many years of cooperation experience and cooperative relationship with overall fender manufacturers, and can provide overall fender services
