Ultra High Molecular Weight Polyethylene Board
uhmwpe
uhmwpe sheet
uhmwpe board
uhmwpe panel
uhmwpe price
uhmwpe supplier
uhmwpe manufacture
Product Details
Product Description
Ultra-high-molecular-weight polyethylene (UHMWPE, UHM) board is a very tough material, with the highest impact strength of any thermoplastic presently made.
UHMWPE board is odorless. tasteless, and nontoxic. It embodies all the characteristics of high-density polyethylene (HDPE) with the added traits of being resistant to concentrated acids and alkalis, as well as numerous organic solvents.
UHMWPE board is highly resistant to corrosive chemicals; has extremely low moisture absorption and a very low coefficient of friction; is self-lubricating and is highly resistant to abrasion, in some forms being 15 times more resistant to abrasion than carbon steel. Its coefficient of friction is significantly lower than that of nylon and is comparable to that of (PTFE, Teflon), but UHMWPE has better abrasion resistance than PTFE.
 |
 |
 |
Properties
|
|
project |
unit |
Test Methods |
index |
|
General Physical Properties |
molecular weight |
X10 |
GB184-80ASTMD4020-81 |
50-1080 |
|
density |
g/cm3 |
GB1033-86 |
0.93-0.98 |
|
|
Volatile matter (moisture) |
％ |
GB2914-82 |
≤0.15 |
|
|
Izod impact strength |
KJ/m2 |
GB1843-80 |
not broken |
|
|
impact strength of beam |
KJ/m2 |
GB1043-86 |
80-130 |
|
|
Tensile breaking strength |
Mpa |
GB1040-79 |
25-40 |
|
|
|
Tensile elongation at break |
％ |
GB1040-79 |
50-600 |
|
thermal performance |
Melting point |
℃ |
ASTMD 2117 |
136 |
|
Vicat softening point |
℃ |
ASTMD 2117 |
80 |
|
|
embrittlement temperature |
℃ |
ASTMD1525 |
≤-70 |
|
|
Linear expansion coefficient |
10-5/℃ |
ASTMD 696 |
0.15 |
|
|
Thermal deformation temperature 0.45Mpa |
℃ |
ASTMD 648 |
110 |
|
|
Electric energy |
volume resistivity |
|
ASTMD 257 |
1017~ 1018 |
|
Dielectric strength |
KV/mm |
ASTMD 149 |
50 |
|
|
Dielectric constant |
106Hz |
ASTMD 150 |
2.30 |
|
|
Dielectric loss tangent |
106Hz |
ASTMD 150 |
≤5×10-4 |
Advantages
UHMWE sheet is one kind of high performance engineering plastic sheet, it has the good functions which other plastic sheet do not have: Excellent abrasion resistance Low coefficient of friction No moisture absorption Corrosion resistant Excellent noise abatement Excellent impact strength Maintains key physical properties to -200°C
Size
|
Standard Size |
5040X1330mm 4730×1230mm 3050X1220mm 6050X1820mm 3030X1550mm 4520X2000mm 3050X3050mm 2000X1000mm 6000X2000mm |
|
Thickness |
2-300mm |
|
Other size can be made according to requirements |
|
