Abosn High Density Polyethylene material Amphimat
Amphimat
Product Details
Feature and Benifits：
|
Series No. |
Size（mm） |
Thickness with Texture（mm） |
Unit weight （KGS） |
EffectiveSurface Area
|
color |
|
XE-07 |
5800x2180
|
88 |
550 |
11.34m² |
Black |
|
XE-08
|
4000x2180 |
88 |
380 |
7.74m² |
Black
|
|
XE-09
|
5800x2180 |
58 |
510 |
11.34m² |
Black
|
|
XE-10
|
4000x2180 |
58 |
348 |
7.74m² |
Black
|
Loading container and calculation：
|
size
|
container |
Quantities |
|
4000x2180x88mm |
20ft ISO Container 52pcs |
22PCS |
|
5800x2180X88mm |
40ft ISO Container |
42PCS |
|
4000x2180x88mm |
44pcs |
|
Operating temperature range (с) |
-60 ~ +70 С |
|
Guarantee of resistance to UV radiation |
YES |
|
Operation on sandy and clayey soils |
YES |
|
Restrictions on maneuvering technique |
no limits |
|
Equipment with locking connectors to fix the plates together (the presence of mounting loops) |
Yes |
|
Availability of the necessary tools and materials, Including connectors, bolt) |
Yes |
|
The presence of a mechanism to configure the road base of the floor mat with turning parts (along the radius) |
Yes |
|
The presence of a ramp |
Yes |
|
Obligatory provision of the assembly drawing of the floor mat |
Yes |
|
Logo engrave |
Yes |
|
Compressional Strength |
40kg/cm2 / 600 PSI |
